Steering wheel button control adapter for Mercedes / VW ACV SWC 42SMC017-0

steering wheel adapter for Mercedes A-class (C169/W169) (10/04->04/08, 06/08->06/12), B-class (T245) (07/05->04/08, 04/08->09/11), C-class (CL203/S203/W203) (02/04->09/07), Sprinter (W906) (04/06->08/13, 08/13->05/18), Vito/Viano (W639) (04/06->08/10, 09/10->03/14) and VW Crafter I (2EC/2EK/2F) (03/06->07/11, 07/11->11/16)
More about the product

We will help you with your purchase

You can return the goods to us within 14 days

Steering wheel button control adapter for Mercedes / VW ACV SWC 42SMC017-0

Description and parameters
Comments0
Evaluation0
Category

Steering Wheel Button Control Adapter for Mercedes and VW ACV SWC 42SMC017-0

Retain the original steering wheel radio control functions when replacing the original radio with a non-original unit. Depending on the vehicle's equipment, the range of functions, and the software of the non-original unit, some functions may be limited or replaced by others. Compare the displayed connectors of the adapter with the connectors in your vehicle to ensure they match visually and technically. Verify if any of the listed original radios were used in the vehicle. Before final installation, check the vehicle's functions, settings, and steering wheel controls.

Intended for Vehicles

Mercedes A-class (C169/W169) (10/2004->04/2008) with radio preparation, ISO connection, and 2 Pin CAN Bus splitter in the interior..
Mercedes A-class (C169/W169) (06/2008->06/2012) with radio preparation, ISO connection, and 2 Pin CAN Bus splitter in the interior.
Mercedes B-class (T245) (07/2005->04/2008) with radio preparation, ISO connection, and 2 Pin CAN Bus splitter in the interior.
Mercedes B-class (T245) (04/2008->09/2011) with radio preparation, ISO connection, and 2 Pin CAN Bus splitter in the interior.
Mercedes C-class (CL203/S203/W203) (02/2004->09/2007) with radio preparation, ISO connection, and 2 Pin CAN Bus splitter in the interior.
Mercedes Sprinter (W906) (04/2006->08/2013) with radio preparation, ISO connection, and 2 Pin CAN Bus splitter in the interior.
Mercedes Sprinter (W906) (08/2013->05/2018) with radio preparation, ISO connection, and 2 Pin CAN Bus splitter in the interior.
Mercedes Vito/Viano (W639) (04/2006->08/2010) with radio preparation, ISO connection, and 2 Pin CAN Bus splitter in the interior.
Mercedes Vito/Viano (W639) (09/2010->03/2014) with radio preparation, ISO connection, and 2 Pin CAN Bus splitter in the interior.

VW Crafter I (2EC/2EK/2F) (03/2006->07/2011) with radio preparation, ISO connection, and 2 Pin CAN Bus splitter in the interior.
VW Crafter I (2EC/2EK/2F) (07/2011->11/2016) with radio preparation, ISO connection, and 2 Pin CAN Bus splitter in the interior.

CAN Bus Information

Connection: ISO connector.
Connection: 2 Pin CAN Bus splitter in the vehicle interior (alternatively CAN high blue / CAN low white or on the climatronic CAN high red-brown / CAN low brown).
Vehicles with radio preparation and radio coding.
Vehicles without radio coding require coding to Audio 20 OEM.
Reverse signal +12V may not always be supported — alternatively on the left side of the vehicle blue-white wire.
For vehicles with OEM ISO radio and ISO connector: LFB Mercedes/Smart/VW multiple models — article 42smc002.

Important Additional Information

A specific brand radio connecting cable is required for full adapter activation.

General Installation Instructions

Pre-Installation Verification

Check all vehicle control functions and settings with the original OEM radio.
Remove the OEM unit without power.
Check all interface connections without power.

Connection and Wiring Order

Perform all settings and configurations without power.
Check the configuration of the radio connecting cable.
Connect the cable according to the instructions to the aftermarket radio.
Connect other wires according to the device instructions.
Connect the main power connection last.
Perform software configuration of the interface according to instructions in the description and BDA.
Configure the aftermarket radio for SWC functions, camera, hands-free, antenna power, etc.
Perform a test of steering wheel control and vehicle communication functions.

Changes to Interface and HU Cable Configuration

Make changes without power.
After changes, follow steps 5–8 above.

In Case of Interface or Vehicle System Failure

Return the original OEM unit to the vehicle.
Turn on the OEM unit.
Wait for CAN Bus to sleep.
Check the hardware configuration of the interface.
After CAN Bus sleeps, follow steps 5–8 above.

When Modifying Connections or Cabling

Modifications should only be performed by professionally trained personnel.
Before connecting, verify compliance with manufacturer requirements and warranty impact.
Before connecting, verify function by measurement and according to vehicle diagrams.
Modifications are at your own risk without a guarantee of functionality.
Modifications are without warranty for potential vehicle, device, or interface damage.
Modifications to pre-installed cabling may void the product warranty.
