Steering wheel button control adapter for Ford ACV SWC 42SFO019-0

steering wheel adapter for Ford Edge (2007->2010), Escape (2008->2012), Expedition (2007->2014), Explorer (2006->2010), Explorer Sport Trac (2007->2010), Five-Hundred (2005->2007), Focus US-model (2008->2011), Flex (2008->2011), Fusion US-model (2006->2012), Mustang (2005->2014), Taurus (2008->2012), Taurus X (2008->2009), F-150 F Series Pickup (2009->2012) and F-250 F Series Super Duty Pickup (2008->2012), Lincoln MKX (2007->2010), MKZ (2007->2010), Navigator (2007->2014) and Zephyr (2006->2012), Mercury Mariner (2008->2010), Milan (2006->2010), Montego (2005->2007), Mountaineer (2006->2010) and Sable (2008->2009)
More about the product

We will help you with your purchase

You can return the goods to us within 14 days

Steering wheel button control adapter for Ford ACV SWC 42SFO019-0

Description and parameters
Comments0
Evaluation0
Category

Steering Wheel Control Adapter for Ford USA / Lincoln / Mercury ACV SWC 42SFO019-0

Maintain the original steering wheel radio control functions when replacing the factory radio with an aftermarket unit. Depending on the vehicle's equipment and the radio software, some control functions may disappear or be replaced by others. Compare the displayed wiring connectors with the connectors in your vehicle and ensure they match both technically and visually. Before installation, verify whether one of the listed original radios was used in the vehicle. Always test the vehicle's functions, system settings, and steering wheel control (SWC) before final assembly.

Suitable for Vehicles

Ford Edge (2007->2010), Escape (2008->2012), Expedition (2007->2014), Explorer (2006->2010), Explorer Sport Trac (2007->2010), Five-Hundred (2005->2007), Focus US model (2008->2011), Flex (2008->2011), Fusion US model (2006->2012), Mustang (2005->2014), Taurus (2008->2012), Taurus X (2008->2009), F-150 F Series Pickup (2009->2012), F-250 F Series Super Duty Pickup (2008->2012)

Lincoln MKX (2007->2010), MKZ (2007->2010), Navigator (2007->2014), Zephyr (2006->2012)

Mercury Mariner (2008->2010), Milan (2006->2010), Montego (2005->2007), Mountaineer (2006->2010), Sable (2008->2009)

CAN Bus Information

Connection: 24 Pin / 16 Pin Ford connector.
Vehicles without OEM audio system.
Vehicles without Rear Seat Entertainment system.
Provided interfaces: +12V ignition, +12V lighting, +12V reverse, GND handbrake.
Maximum output load: 100 mA.
For consumption over 100 mA: min. relay coil resistance 75 Ω (1 relay) or 150 Ω (2 relays).

Important Additional Information

A connecting cable for the specific radio brand is required for full adapter activation.

General Installation Instructions

Verification Before Installation

Check all control functions and vehicle settings with the original OEM radio.
Remove the OEM unit without power.
Check all interface connections without power.

Connection and Wiring Order

Perform all settings and configurations without power.
Check the configuration of the connecting cable.
Connect the cable according to the instructions to the aftermarket radio.
Connect other wires according to the device instructions.
Connect the main power connection last.
Perform software configuration of the interface according to the instructions in the description and BDA.
Configure the aftermarket radio for SWC functions, camera, hands-free, antenna power, etc.
Test the steering wheel control and vehicle communication functions.

Changing the Interface and HU Cable Configuration

Make changes without power.
After changes, follow steps 5–8 above.

In Case of Interface or Vehicle System Failure

Return the original OEM unit to the vehicle.
Turn on the OEM unit.
Wait for the CAN Bus to go to sleep.
Check the hardware configuration of the interface.
After the CAN Bus goes to sleep, follow steps 5–8 above.

In Case of Wiring or Cabling Modifications

Only professionally trained personnel may make modifications.
Before connecting, verify compliance with manufacturer requirements and impact on warranty.
Before connecting, verify function by measurement and according to the vehicle schematic.
Modifications are made at your own risk without warranty of functionality.
Modifications are made without warranty for potential damage to the vehicle, device, or interface.
Modifications to pre-installed cabling may void the product warranty.
