Parkovací kamera BC SUZ-02
Reversing camera for Suzuki Kizashi, mounted in place of the license plate light
More about the product
More about the product
We will help you with your purchase
- You can return the goods to us within 14 days
Parking camera for Suzuki Kizashi (BC SUZ-02)
Parking camera installed into the license plate light area.
The camera is suitable for the following vehicles:
- Suzuki Kizashi
Technical specifications
- image sensor: PC3089 1/3"
- option to turn on / off the display of guiding trajectories (guide lines)
- electronic shutter: 1/60 1/10000 sec.
- minimum illumination: 0.1 lux
- signal-to-noise ratio: > 48 dB
- TV system: NTSC
- number of TV lines: 600
- effective pixels: 668 × 576
- weather protection: IP67
- viewing angle: 170°
- camera body: durable plastics "private housing"
- image display: mirrored
- white balance: automatic
- operating temperature: from -30 °C to +70 °C
- AGC, BLC, white balance: automatic
- signal cable: length 6.2 m terminated with CINCH / RCA connector
- video output: 1.0 V / 75 ohm
- power cable length: 1 m
- power supply: 12 V DC
- power consumption: <1 W
Note
The camera is intended for non-original (aftermarket) radios with a CINCH AV input. Use with an original radio may require connecting a video adapter for the parking camera!
| Catalog number | BC SUZ-02 |
| Brand | TSS Group |
