ACV FLY 4 - yellow
copper power cable, cross section 4 mm², yellow insulation
More about the product
More about the product
ACV FLY 4 - yellowIn stock (100 m) 1,97 EUR
ACV FLY 4 - blackIn stock (79 m) 1,97 EUR
ACV FLY 4 - redIn stock (64 m) 1,97 EUR
ACV FLY 4 - blueIn stock (88 m) 1,97 EURWe will help you with your purchase
- You can return the goods to us within 14 days
Tip
Power cable 4 mm² ACV FLY 4 - yellow
ACV FLY 4 is an ACV power cable made in Germany according to DIN/ISO standards for high-quality wiring in vehicles. Unlike the often used installation cables with copper-aluminum conductors with poor electrical and mechanical properties, this cable offers the highest conductivity with the lowest electrical resistance for optimum current flow due to the exclusive use of conductors made of 99.9% pure copper. The excellent mechanical properties of copper also ensure optimum contact reliability with low contact resistance when crimping or soldering.Main characteristics
- High quality power cable.
- Insulation according to ISO 6722-1.
- Insulation material: lead-free soft PVC.
- Colour according to ISO 6722-1: yellow.
- Conductor according to DIN 13602: soft annealed electrolytic copper Cu-ETp1/CW003A bare.
- Nominal cross-section: 4,0 mm².
- Outer diameter: 4,0 mm (+/-0,2 mm).
- Wire diameter: max. 2,54 mm.
- Diameter of one wire: 0,305 mm.
- Number of individual wires: 52.
- Resistance: 4,8 Ohm/km at 20°C.
- Copper density: 38,4 kg/km.
- Price for 1 metre of cable.
| Catalog number | 50-400-103-1 |
| Brand | ACV |
| Links | Official web presentation |
