Universal parking camera (BC MINI)

Universal parking camera

Parking camera of small dimensions - 12 V / 24 V, with the possibility of switching on auxiliary trajectories (guide lines), angle of view 170°, metal camera body.

Technical parameters of the camera

• PC3089 - 1/3" sensing chip
• Possibility to turn on / off the display of auxiliary trajectories (guide lines)
• Electronic aperture: 1/50 1/12000 sec
• Minimum illumination: 0.01 lux.
• Signal-to-noise ratio: > 48 dB.
• TV system: NTSC (every display is compatible)
• Effective pixels: 720 x 488
• Number of TV lines: 600
• Weather protection: IP68
• Scanning angle: 170°
• Video output: 1.0V / 75 ohm
• White balance: automatic
• Operating temperature: from -30°C to +75°C
• Signal cable length: 7 m terminated CINCH / RCA connectors (male)
• Power cable length: 1 m
• Power supply: 12V / 24V
• Mirror image
• Dimensions: 38 x 37 x 36 mm (W x D x H) including holder

Note:
The camera is intended for non-original (re-assembled) radios with CINCH AV input. Use with the original radio may require the connection of a video adapter for the parking camera!
