OEM parking camera Hyundai, Kia (BC HYU-07)

OEM parking camera for Hyundai, Kia

OEM color parking camera for installation in the rear license plate lamp. The camera includes a place to place the socket with the bulb from the original license plate light.

Camera suitable for the following vehicles:

• Hyundai i10 II. (2014 ->)
• Hyundai i20 I. [PB] (8/2008 -> 2015)
• Hyundai i20 II. (2015 ->)
• Hyundai i30 I. (9/2007 -> 2/2012)
• Hyundai Veloster (2011 ->)
• Hyundai Genesis Coupe

• Kia Soul I. [AM] Facelift (11/2011 ->)
• Kia Rio III. (9/2011 -> 2016)(does not fit 2017 -> model)

Technical parameters of OEM camera for Hyundai, Kia:

• sensing sensor: PC3089 1/3"
• the option to turn on / off the display of auxiliary trajectories (guide lines)
• electronic aperture: 1/60 1/10000 sec.
• minimum illumination: 0.1 lux
• signal / noise ratio: > 48 dB
• TV system: NTSC
• number of TV lines: 600
• effective pixels: 668 × 576
• weather protection: IP67
• scanning angle: 170°
• camera body: durable plastic "private housing"
• image display: mirror image
• white balance: automatic
• operating temperature: from -30 °C to +70 °C
• AGC, BLC, white balance: automatic
• signal cable: length 6.2 m terminated with CINCH / RCA connector
• video output: 1.0V / 75 ohm
• power cable length: 1 m
• power supply: 12 V DC
• consumption: <1W

Camera dimensions:

• base: 37.5 x 97 mm

Note:
The camera is intended for non-original (re-assembled) radios with CINCH AV input. Use with the original radio may require the connection of a video adapter for the parking camera!
