OEM enclosure Basser 12" for Audi Q7

OEM enclosure Basser 12" for Audi Q7

An OEM enclosure is a custom-made box that fits precisely into the side panel of the boot or into a space intended for hidden installation in the vehicle. OEM enclosures are the ideal compromise between power, sound and boot space. Our range includes a wide selection of OEM boxes for the most common vehicle models. This enclosure is made for the Audi Q7 (2005 and newer). Installing the OEM box requires moderate skill: it needs to be fixed at the rear to one of the mounting points in the car, or a bracket must be made, e.g. from MDF or a wooden board.

Technical parameters of the OEM enclosure for Audi Q7

• Type: sealed enclosure.
• Volume: 38 l.
• Diameter: for 30 cm (12") subwoofer.
• Location: in place of the spare wheel.
• Mounting depth for subwoofer: 180 mm.
• Weight: 13,0 kg.
• The enclosure is covered with grey carpet and fitted with a terminal for connecting the wiring.

Catalog number	OBGL.AUDI.07
Brand	Basser
Links	Official web presentation
Loudspeaker typeEmpty enclosures are most often bass-reflex or closed constructions.	Closed enclosure
Subwoofer hole sizeHole for a given subwoofer diameter category. For a 300mm subwoofer, the hole is most often approx. 28.3 cm. The mounting diameters of subwoofers are usually standardized, so there is no need to adjust anything.	30cm (12")
Loudspeaker volumeThe volume of an empty enclosure is usually given as the total volume including the walls of the box. Some manufacturers also state the net volume, i.e. the pure volume of air in the box after subtracting everything else. We then state the net volume in brackets with the description "net".	38 years old
What is the baffle made of?Subwoofer enclosures are usually made of 18-22 mm MDF board or pressed chipboard. Due to its higher strength, MDF board is a better material than ordinary chipboard.	MDF
Connection terminal typeThe connection terminal is most often from the back of the sound box, but sometimes also from the side. It is mostly a plastic terminal with spring clamps for the speaker cable.	Plastic screw terminal
CoverThe vast majority of the enclosure is covered with either black or anthracite carpet.	Carpet
Cover colorColored carpet or leather upholstery.	Gray highlights
Other	Recess 322 mm
