Mercedes C-Class, E-Class Connects2 steering wheel button control adapter CTSMC010.2

Mercedes steering wheel adapter

Adapter for activating the control buttons on the steering wheel when buying an aftermarket car radio with an ISO connector (included in the adapter) for vehicles:

• Mercedes-Benz C-Class [W204] (2012 -> 01/2015)
• Mercedes-Benz E-Class [C207/A207] (2012 -> 2017)

Important additional information

• Cars with OEM audio system with FAKRA connector - without OEM active audio system.
• The adapter supports the buttons on the steering wheel to control the phone.
• It allows you to set the time and date from the controls on the steering wheel.
• For aftermarket Sony, Kenwood, Panasonic, JVC, Pioneer, Blaupunkt, Clarion, Alpine, LG, Zenec, Becker car radios.
• To fully activate the adapter, it is necessary to order a connecting cable for the given brand of car radio! (see below)

The adapter includes wires with analog signals

• +12 V after turning on the key (vol. 15).
• +12 V after turning on the vehicle lighting.
• +12 V after engaging reverse gear.
• Speed pulses.

Properties

• CAN Bus.
• Control from the steering wheel.
• Plug&Play easy installation with original cables.
• Hands-free control from the steering wheel.
• Lighting.
• Hand brake.
• Speed pulses.
• Information on reverse gear inclusion.
• +12 V after switch on ignition (Vol. 15).
• Car function settings.
