Eton MA 2 amplifier

Eton MA 2 Amplifier

The new MA power amplifiers - the six-channel MA 6, two and four-channel models MA 2 and MA 4, and the monoblock MA 1 are successors to the award-winning ETON MINI and ETON POWER amplifiers. The MA series is a new design line with a complete set of features, top-notch sound, and high performance, compactly designed for easy installation. Built on modern class D amplifier technology, these amplifiers deliver high output power combined with fine resolution, low distortion and offer HIGH GRADE CAR AUDIO developed in Germany. The MA amplifiers feature premium electronics housed in beautifully designed enclosures made from simple die-cast aluminum, anodized in a matte bronze finish. The die-cast aluminum enclosures act as heat sinks, ensuring highly efficient thermal management. The top panel with the ETON logo is removable and can be rotated 180° for optimal cosmetic integration in both directions. The MA amplifiers offer top-side control with all settings accessible from the top of the amplifier, concealed under the top plate once adjustments are complete. It covers all adjustment needs imaginable: high and low-frequency filters, adjustable high-level input voltage, adjustable high-level input impedance (EPS load), and gain control. The MA series continues to impress with small yet practical design features, such as a built-in tool for easy adjustment and a LED light indicating the amplifier's operating status, also serving as a light source for easier control adjustments in dark spaces. Removable power and audio signal connectors and variable mounting feet complete the thoughtful feature set of the MA series. Another bonus is the stackable design for installing two identical amplifiers on top of each other, fitting into tight spaces, or additional mounting points and blanking holes for even greater versatility. Internal values are equally impressive - multi-layer boards, high-quality electronic components, and first-class manufacturing form the basis for the advanced class D amplifier circuits, which are highly efficient. It offers premium sound for demanding listeners with the lowest distortion and highest control. Whether it’s a six-channel amplifier for fully active operation of a three-way front system or a monoblock for powerful subwoofers, the MA series offers an unprecedented choice.

Key Features

• Newly developed advanced class D amplifier technology.
• Newly designed and high-quality die-cast aluminum enclosure in gunmetal grey with a removable top plate of milled aluminum (rotatable by 180°).
• Adjustable high-pass 12 dB/oct and low-pass 12 dB/oct.
• Automatic turn-on function (SIG / DC).
• Start-Stop function.
• Adjustable gain 0.45 V - 6 V.
• Adjustable high-level input impedance (EPS load) for each pair of channels: 10 / 150 / 600 Ω.
• Adjustable high-level input signal voltage for each pair of channels: 1 - 15 V / 15 - 40 V.
• High-level inputs, low-level inputs (RCA) and low-level outputs (RCA).
• Removable connectors for power and audio signal connection.
• Variable mounting feet for quick and easy installation.
• Option for hidden mounting with additional mounting points and blanking holes.
• Amplifier stackable design.
• Newly designed status LED light strip.
• Remote control for subwoofer level adjustment included.
• Developed in Germany.
