ACV heat shrink tubing with adhesive 3.2 mm / 7.5 m

Be the first to rate the product
Heat shrink tubing with adhesive, diameter before shrinking 3.2 mm, length 7.5 m
More about the product
35,70 EUR
Catalog number: 34135-32
1 to 4 weeksWatchdog
We will help you with your purchase
  • You can return the goods to us within 14 days
ACV heat shrink tubing with adhesive 3.2 mm / 7.5 m

ACV Heat Shrink Tubing with Adhesive 3.2 mm / 7.5 m

Heat shrink tubing is elastic, thin-walled, polyolefin, and heat-shrinkable tubing for versatile use. Low shrinkage temperature, excellent flexibility, and mechanical strength are its main features. Moreover, the tubing is self-extinguishing. It can be used for reliable insulation of joints and components in electrical engineering, electronics, and the automotive industry, for protecting pipes from corrosion, as mechanical protection and reinforcement of electrical wire terminations or joints, and for bundling wires or cables during vehicle sound system installation.

Main features

  • Set of heat shrink tubing with adhesive.
  • Inner diameter before heating: 3.2 mm.
  • Inner diameter after heating: 1 mm.
  • Wall thickness after heating: 0.95 mm.
  • Adhesive layer: 0.35 mm.
  • Length: 7.5 m.
  • Color: black.
  • Material: dual-wall polyolefin tubing with adhesive.
  • Operating temperature: -45°C to +125°C.
  • Shrink ratio: 3:1.
  • Standard: UL224 VW-1 125°C 600 V.
  • Approvals: UL, CSA.
  • Tensile strength: ASTM D 2671 (10.4 MPa).
  • Elongation: ASTM D 2671 (300%).
  • Tensile strength after thermal aging: UL 224 158°C x 168 Std. (>= 7.3).
  • Thermal resistance: UL 224 250°C x 4 hours.
  • Elongation after aging: UL 224 158°C x 168 hours (>=100%).
  • Dielectric strength: IEC 243 (>= 15kV/mm).
  • Volume resistivity: IEC 93 (>= 1x1014 Ohm.cm).
  • Copper resistance: UL 224 158°C x 168 hours.
  • Copper corrosion: UL 224 158°C x 168 hours.
Catalog number34135-32
BrandACV
LinksOfficial web presentation
