ACV Heat Shrink Tubing 1.6 mm / 15 m
Heat shrink tubing is elastic, thin-walled, polyolefin-based, and heat-shrinkable tubes for versatile use. Low shrink temperature, excellent flexibility, and mechanical strength are their defining features. Additionally, the tubing is self-extinguishing. It can be used for reliable insulation of joints and components in electrical engineering, electronics, and the automotive industry, protection of pipes against corrosion, mechanical protection, and reinforcement of terminations or joints of electrical wires and bundling wires or cables when installing vehicle sound systems.Main Features
- Heat shrink tubing set.
- Inner diameter before heating: 1.6 mm.
- Inner diameter after heating: 0.8 mm.
- Wall thickness after heating: 0.32 mm.
- Length: 15 m.
- Color: Black.
- Material: Thin-walled cross-linked polyolefin.
- Operating temperature: -55 °C to +125 °C.
- Shrink ratio: 2:1.
- Standard: UL224 VW-1 125 °C 600 V.
- Approvals: UL, CSA.
- Tensile strength: ASTM D 2671 (10.4 MPa).
- Elongation: ASTM D 2671 (200%).
- Tensile strength after thermal aging: UL 224 158 °C x 168 Std. (>= 7.3).
- Heat resistance: UL 224 250 °C x 4 hrs.
- Elongation after aging: UL 224 158°C x 168 hrs. (>=100%).
- Dielectric strength: IEC 243 (>= 15kV/mm).
- Volume resistivity: IEC 93 (>= 1x1014 Ohm.cm).
- Copper resistance: UL 224 158°C x 168 hrs.
- Copper corrosion: UL 224 158°C x 168 hrs.
| Catalog number | 34125-16 |
| Brand | ACV |
| Links | Official web presentation |
