Blaupunkt Bremen SQR 46 DAB
The Blaupunkt Bremen SQR 46 DAB is a modern reissue of the legendary Bremen SQR 46 car radio from 1986. It preserves the typical 1980s look while offering contemporary features such as DAB/DAB+, Bluetooth Twin Connect, USB, AUX, SD/SDHC, iPod/iPhone control and Variocolour backlighting.
DAB+ and High-End CODEM tuner
The radio uses a High-End Blaupunkt CODEM tuner and supports FM, AM and DAB/DAB+. It offers 15 DAB presets and 25 analog presets, Radiotext, DLS, Service Following and other features for stable reception.
Bluetooth Twin Connect
Integrated Bluetooth 2.1 + EDR supports HFP, PBAP, A2DP, AVRCP and SPP. The radio remembers 5 paired devices and, thanks to Twin Connect, allows simultaneous connection of 2 phones for calling. An internal microphone and an input for an external microphone are available.
2× USB, SDHC and AUX
The Bremen SQR 46 DAB has 1× front USB, 1× rear USB, a front SD/SDHC slot and a front 3.5 mm AUX. It supports SDHC cards up to 32 GB and MP3 and WMA formats. Apple iPod/iPhone control is possible via USB for compatible devices.
3-band semi-parametric equalizer
The radio offers a 3-band semi-parametric EQ, Bass/Treble, Balance/Fader, X-Bass and sound presets Rock, Pop and Classic. The built-in amplifier provides 4 × 50 W max. / 4 × 24 W RMS at 14.4 V.
RCA 4 V and Sub-Out
For external amplifiers there is a 4-channel RCA pre-out at 4 V and a separate Sub-Out with adjustable level and frequency. The radio also supports analog programmable steering wheel control.
Key features
- Retro design based on the original from 1986.
- FM/AM High-End Blaupunkt CODEM tuner.
- Integrated DAB/DAB+ tuner.
- Bluetooth Twin Connect.
- Memory for 5 paired devices.
- Simultaneous connection of 2 phones.
- Internal and external handsfree microphone.
- Front and rear USB.
- SD, SDHC and MMC reader.
- Front 3.5 mm AUX input.
- Support for MP3 and WMA.
- Control of compatible Apple iPod/iPhone.
- 3-band semi-parametric equalizer.
- X-Bass function.
- Maximum power 4 × 50 W.
- 4-channel RCA pre-out 4 V.
- Separate Sub-Out.
- Analog programmable steering wheel control.
- Variocolour RGB backlighting for display and buttons.
- Short installation depth 110 mm.
- DAB+ antenna, external microphone and IR remote control included.
Technical specifications
- Format: 1DIN.
- Tuner: FM / AM / DAB / DAB+.
- Bluetooth: 2.1 + EDR.
- Bluetooth profiles: HFP, PBAP, A2DP, AVRCP, SPP.
- Paired devices: 5.
- Simultaneously connected phones: 2.
- USB: 2× USB 2.0.
- Memory card: SD / SDHC / MMC.
- Max SDHC capacity: 32 GB.
- AUX: Front 3.5 mm.
- Formats: MP3, WMA.
- iPod/iPhone: Yes.
- Equalizer: 3-band semi-parametric.
- X-Bass: Yes.
- Sound presets: Rock, Pop, Classic.
- Maximum power: 4 × 50 W.
- RMS power: 4 × 24 W at 14.4 V.
- RCA pre-out: 4 channels / 4 V.
- Sub-Out: Yes.
- SWC: Yes, analog programmable.
- Backlight: Variocolour RGB, 4096 colors.
- Display: 1-line / 9 characters.
- Panel: Fixed.
- Dimensions: 58 × 178 × 110 mm.
- Weight: approx. 0.85 kg.
What's in the box
- Blaupunkt Bremen SQR 46 DAB.
- External Bluetooth microphone.
- DAB+ adhesive glass antenna.
- IR remote control.
- Mounting and connection accessories.
About the brand
Blaupunkt is a traditional, globally recognized brand with a long history in automotive electronics. For decades it has been primarily associated with car radios and practical automotive accessories. Today’s range includes modern car stereos with Bluetooth, handsfree, digital DAB+ radio, USB or support for Apple CarPlay and Android Auto. Popular retro-style models are also available, combining classic looks with current technologies. These retro car radios are excellent for youngtimers and classic vehicles where maintaining the original appearance and atmosphere of the interior is important. The brand also offers subwoofers, car antennas, reversing cameras, monitors and other installation accessories. Blaupunkt appeals to drivers seeking a well-known brand, simple and functional solutions, good compatibility and a balanced price-performance ratio.
| Catalog number | BREMEN SQR 46 DAB |
| Brand | Blaupunkt |
| Links | Official web presentation |
| Car radio sizeCar radios are divided into 2 basic sizes, 1DIN car radios and 2DIN car radios . 1DIN size car radios - the exact dimensions including the metal frame where the car radio is inserted are 184 x 53 mm, the external dimensions of the branded 1DIN car radio are 188 x 59 mm. We know 2DIN car radios from newer vehicles, a classic example is the VW Golf IV with navigation. The dimensions of a 2DIN car radio without a metal frame are 180 x 101 mm, the external dimensions of a branded 2DIN car radio are 189 x 119 mm. | 1DIN |
| CD driveCar radios with CD drive. Car radios that have an input slot for inserting a CD. | No |
| Integrated BluetoothBluetooth is a communication technology used for wireless connection between two or more electronic devices. A mobile phone, for example, can be connected to a car radio with built-in Bluetooth. Most car radios for 2017 and later can also wirelessly stream (play) music via Bluetooth -> A2DP function. | Yes |
| USB inputThe USB input of the car radio is used to connect a USB flash drive or smartphone. Today, playing music via USB is the most popular way to listen to music in the car. The USB input can be front (on the front panel of the car radio) or rear (on the back of the cable). | Yes |
| SD card accessModern branded car radios can play SDHC SD cards up to 32 GB, sometimes even 64 GB. The SD card slot is behind the front panel in most car radios. | Yes |
| Supported formats via USB inputList of all supported formats (MP3, AAC, Flac, DivX, etc.) that the car radio can play via USB input. | MP3, WMA |
| Apple CarPlayApple CarPlay is a completely new option for connecting a smartphone to a car radio that has the Apple CarPlay function. The connection is only by cable, thanks to the high data flow. You click on the Apple CarPlay icon on the car radio screen and application icons appear on the car radio screen like on a smartphone, and you can continue to control everything using the car radio. It also works with voice control and Siri. | No |
| Android AutoGoogle's Android Auto is a completely new option for connecting a smartphone to a car radio that has the Android Auto function. The connection is only by cable, thanks to the high data flow. The Android OS requirement is at least version 5.0. You click on the Android Auto icon on the car radio screen, and application icons appear on the car radio screen like on a smartphone, and you can continue to control everything using the car radio. Voice control and GPS signal also works. | No |
| Car radio performanceThe performance of the car radio shown in maximum values. This is therefore the MAX value. The performance of the internal amplifier of the car radio. Today, the RMS power of a car radio ranges from 17 - 30 W RMS per channel. | 4 x 50 W |
| Number of RCA outputsRCA outputs , colloquially called "cinches", are used to connect an external amplifier or active subwoofer. Aftermarket car radios are usually equipped with 1 to 3 pairs of RCA outputs. FRONT, REAR and SUB are used. It also depends on how many volt outputs the car radio is equipped with. More basic models of car radios have 2V outputs, more expensive units have 4V and more. The higher the specified value, the less power demands are placed on the external amplifier and the sound quality increases. | 3 pairs |
| Output level on RCAAn important parameter if you are going to install an external amplifier. If you purchase a car radio with a basic value, i.e. 2V outputs, then greater demands will be placed on the power of the amplifier. As the value increases, e.g. 4V or 5V, the power of the external amplifier increases significantly, in layman's terms. A car radio with strong outputs therefore has the advantage that you do not pull so much power through the amplifier and thus achieve a better sound, as external amplifiers lose control at higher loads. | 4 V |
| Backlit buttonsColor options for the backlight of the car radio buttons. | Variable |
| External microphone included in the packageThe external microphone is connected from the back of the car radio to the input marked "MIC". For ideal sound quality during a phone call, we recommend placing the external microphone on the left "A" pillar at the point where the "A" pillar and the roof panel connect to each other. A very good position to place an external microphone is also near the central rear-view mirror. | Yes |
| Remote control includedCard IR remote control of the car radio, thanks to which certain functions of the car radio incl. control the volume from the hand, remotely. | No |
| Removable front panelPossibility to remove the entire front panel of the car radio by pressing the side button. A very effective weapon against car radio theft. We recommend not hiding the panel in the vehicle, but taking it with you. Alternatively, place the panel in a hidden place in the trunk, but not when leaving the car, but before parking. You never know when a thief might be watching you. | No |
